| H. P. | 3 |
| No. of Cylinder | 1 |
| R.P.M. of Compressor | 700 |
| Bore & Stroke in mm | 98.425 x 59.53 |
| Piston Displacement cu.ft.per/min | 11.30 |
| Max. Tank Pressure p.s.i | 170 |
| Max. Tank Capacity mm | 460 x 1067 |
| Tank Capacity Litres | 212.76 |
| Tank Capacity Imperial Gallon | 46.80 |
| Approx. weight w/o. Motor kgs | 225 |
Body : Compressor’s body are made from high grade castings.
Piston : Made of special cast Iron & Alluminium Alloy.
Crankshaft : Is made of special Forged steel ground to the close tolerance for high effeciency.
Connecting Rod : Made from bronze or Forged steel.
Air Receiver : Made from mild steel & hydraulically tested, safety valve, Non return valve, Air cock & drain cock are made from brass.
Automatic pressure switch : Which stops electrically, the motor when the air in the tank raises up to the pre-equalated pressure & the pressure goes down. The motor will automatically run again to compress the air.
